Petrofer’s lubrication for metal forming operations from neat oils, oil based emulsions, dispersions, synthetic products and pastes, to stamping oils and rolling oil which evaporate free of residues. At the same time, the products are used in a wide range of applications, including high quality forming lubricants for wire drawing, solid forming, fine cutting, stamping, punching, punching, deep drawing and rolling processes.
By forming partnerships in the field of forming technology, we have assisted our customers to: achieve high economic benefits; the service life of water soluble products is extended to obtain higher quality products -through process optimization and improve friction and wear properties.
All products are tailored to the application of the forming process and special standards. Therefore, Petrofer’s products can ensure high productivity in metal forming processing.
DRAWLUB C is a high performance copper drawing solution that is widely used in large drawing to ultra-fine drawing processes. ISOLUBE 4600 includes semi-synthetic and conventional pure oil-based aluminum wire-drawing lubricants for a wide range of mechanical technologies and applications. DRAWLUB ST is a water-soluble lubricant used in processes such as medium to small drawing of ferrous metals. DRAWLUB ST products are not only suitable for ferrous metal bare wire, but also for drawing galvanized wire, coated wire, etc. ISOFORM 900 is a chlorine-free, pure oil drawing oil for steel wire and profiles, mainly used for ferrous metal, high-strength alloy steel and spring steel drawing. DRAWLUB TD is a pure oil-based multifunctional drawing oil, mainly used for stainless steel wire drawing as well as nickel alloy and titanium wire drawing.
| Model | Range | Concentration | |
| DRAWLUB C 100 0.15 mm<15.0 mm |
Emulsified products, suitable for copper and copper alloy large drawing and medium drawing wire equipment. | 8.0% 20.0% |
|
| DRAWLUB C 200 0.15 mm<8.00 mm |
Emulsified products, especially suitable for surface coating and electroplating in the drawing and multi-head drawing equipment. | 5.0% 15.0% |
|
| DRAWLUB C 300 0.10 mm<3.50 mm |
Emulsified products, suitable for waste enameled wire production, small drawing and multi-head drawing equipment. | 5.0% 15.0% |
|
| DRAWLUB C 400 0.015 mm<0.45 mm |
Fully synthetic products, suitable for small drawing, micro drawing, multi-head drawing and waste enameled wire drawing process. | 1.0% 11.0% |
|
| DRAWLUB C 500 0.05 mm<1.20 mm |
Semi-synthetic solution, suitable for thin and micro-thin line drawing, excellent cleaning and lubrication performance. | 1.0% 11.0% |
|
| DRAWLUB C 900 0.10 mm<20.0 mm |
Neat oils products, suitable for copper and copper alloy electronic wire profiled section wire drawing. | 100% | |
| Model | Range | Concentration | |
| ISOLUBE 4640 0.15 mm<6.50 mm |
High performance semi-synthetic neat oil for drawing pure aluminum and aluminum alloy wire. Especially suitable for multi-head wire drawing machine, good oxidation resistance, low consumption. | 40 61 |
|
| ISOLUBE 4660 0.15 mm<6.50 mm |
High performance semi-synthetic neat oil for drawing pure aluminum and aluminum alloy wire. Especially suitable for multi-head wire drawing machine, good oxidation resistance, low consumption. | 40 61 |
|
| ISOLUBE 4600 0.90 mm<9.50 mm |
High performance neat oil for aluminum and aluminum alloy wire drawing. Suitable for all types of wire drawing machine. | 130 170 530 |
|
| ISOLUBE MG GREASE 0.90 mm<9.50 mm |
Grease suitable for aluminum and aluminum alloy wire drawing. Especially suitable for single die wire drawing machine. | TP+51℃ V100 16.0 |
|
| Model | Range | Concentration | |
| DRAWLUB ST 100 0.07 mm<4.0 mm |
Water-soluble drawing lubricant. Suitable for drawing process of bare steel wire, galvanized and copper plated steel wire. | 3.0% 15.0% |
|
| ISOFORTV 900 0.10 mm<12.0 mm |
Viscosity/40℃=10.0-500mm2/s Neat oil drawing oil without chlorine. Suitable for drawing process of iron and steel alloy, chrome alloy and spring steel wire. |
100% | |
| DRAWLUB TD 0.10 mm<12.0 mm |
Viscosity/40℃=10.0-500mm2/s Neat oil drawing oil with chlorine. Suitable for stainless steel, nickel and titanium wire drawing process. |
100% | |
Other ISOFORM 900 series products are used for higher requirements cold forming processing. The ISOFORM 9000 series include lubricating pigments, namely sol-gel lubricants, can better used in cold forging and subthermal precision forging processes.
| Model | Range | Concentration | |
| ISOFORM 911 ISOFORM 922 ISOFORM 933 |
High performance concentrated products; suitable for heavy duty forming of steel and stainless steel, such as spline shaft, piston pin, transmission shaft, sparkplugshell, wheel nut. | 59 68 62 |
|
| ISOFORM 944 ISOFORM 955 ISOFORM 966 |
Multi-purpose cold forming processing oil. Suitable for steel and alloy steel forming processing. Such as: nut, screw, bolt, thread forming. | 85 95 110 |
|
| ISOFORM 988 ISOFORM 999 |
Cold forming oil. Suitable for cold and thread forming of steel. Such as: self-tapping screws, German industrial standard screws and various types of rivets. | 86 46 |
|
| Model | Range | Concentration | |
| ISOFORM 9100 ISOFORM 9200 |
Dispersed (sol-gel) products. Used for cold and warm forging of power transmission parts. Such as:bearing processing of constant speed universal joint. | 20S 60S |
|
| Model | Range | Concentration | |
| ISOFORM 950 ISOFORM 960 |
Multi-purpose cold forming oil. Suitable for steel, aluminum, copper and alloy forming processing, especially suitable for mechanical lubrication. | ISO VG-Class | |
| ISOFORM 970 | Aluminum cold forming oil. Suitable for spare parts, screws, bolts, nuts, rolled thread and rolling drawing. | ISO VG-Class | |
DRAWLUB S is a neat oil for fine stamping and sheet metal forming without chlorine. DRAWLUB S provides value-added optimization for car driveline technology and chassis components production line. DRAWLUB R is an ester metal processing oil lubricant with low volatility, multi-purpose, environmental friendly and suitable for micro-lubrication. DRAWLUB TD is a multifunctional oil-based lubricant for sheet metal forming apply to stainless steel, nickel alloy and titanium component. DRAWLUB 3000 is suitable for multifunctional metal forming for higher requirements.
| Model | Range | Concentration | |
| DRAWLUB S | Precision blanking and sheet forming processing oil. Chlorine free, wide range of applications. Such as: transmission components, hinges, fire extinguishers, etc. | 30<300 | |
| DRAWLUB R | Low volatile metal forming processing oil. Wide range of use, multi-purpose, environment-friendly products, especially suitable for micro lubrication system. | 5<1500 | |
| DRAWLUB TD | Metal processing oil which can be widely used, also suitable for stainless steel wire drawing. | 8<6000 | |
| DRAWLUB 3000 | Emulsion type, solution type, water- based paste type, dispersed type products, wide range of adaptation. | ||
| Model | Range | Concentration | |
| ISOLUBE V 72 ISOLUBE V 73 ISOLUBE V 74 ISOLUBE V 75 |
Solvent-based stamping oil,suitable for punching cutting/stamping/punching. Without residue after drying, compatible with refrigerant (CFC,R134a), self-volatilization without washing. | 55<100 | |
| ISOLUBE V 76 | Semi - synthetic finned oil suitable for sheet metal punching/stamping/deep drawing. Volatilization without residue, compatible with refrigerant (CFC,R134a), does not contain VOC prohibited by EU 1999/13/EC. | >100 | |
| ISOLUBE 3400 | Low viscosity punching/stamping/deep drawing oil. Suitable for light and medium load stamping and metal forming processing. | 4mm2<50mm2 | |
The ISO-MILL product line is a customised rolling oils, especially for wire production in continuous casting mills. It is also suitable for pipe production of various metals in Pilgrim cold rolling mill and roll forming mill. ISOLUBE CR and ISOADD are groove additives that improve lubrication performance and surface smoothness.
| Model | Range | Concentration | |
| ISO-MILL K 9 | The emulsion is suitable for cold rolling and hot rolling of aluminium and aluminium alloys. Such as: aluminum rod continuous casting and rolling. | 5.0% 20.0% |
|
| ISO-MILL RS | Cold rolled emulsion suitable for steel and alloy steel.Such as: steel rolling forming process. | 5.0% 20.0% |
|
| ISO-MILL CU | Emulsion and neat oil,suitable for hot and cold rolling processes of copper and copper alloys. Such as: cold rolling of steel pipe and continuous casting and rolling of copper pipe (namely: CCR) | 1.0% 25.0% |
|
| Model | Range | Concentration | |
| ISO-MILL CBA | Suitable for steel, aluminum, copper sheet metal cold rolling process. Such as: cold forming process for profile and oval pipe . | >2 <50 |
|
| ISO-MILL RS | Neat oil,suitable for hot and cold rolling process of steel and alloy steel.Such as: rail rolling process. | >20 <300 |
|
| Model | Range | Concentration | |
| ISOADD | An additive used to control the stability, lubricity and surface properties of emulsion products. For example, directly add to cold and hot rolling emulsion products systems using ISO-MILL. | Additives | |
| ISOLUBE CR | An additive for cold rolling base oil to improve the lubricity of cold rolling oil and the brightness of metal sheet, can be used for ISO-MILL CBA product series. | Additives | |
